The 90ESSE system is a sunshade tent with adjustable blades, designed to provide light control, visual comfort, and weather resistance in contemporary buildings.
Solar control and environmental comfort
The 90ESSE system is an advanced solution for solar shading, ideal for improving the thermo-visual comfort of indoor spaces. The adjustable blades from 0° to 90° allow for modulation of light and privacy, contributing to the building's energy efficiency and the well-being of its occupants.
Shaped blades and durable materials
The blades, 90 mm wide and made of pre-painted matte aluminum, feature a characteristic "S" shape designed to optimize shading and aesthetic appeal. With a minimum thickness of 0.45 mm, side edging, and anti-noise gaskets, they ensure robustness, quiet operation, and long-lasting durability.
Reliable operating system
The system is equipped with 8 mm texband tapes, UV-resistant and certified for 100,000 operating cycles, ensuring reliability and longevity. Blade orientation is managed by Terilene cords with Aramid and Kevlar, fixed with stainless steel hooks that can be opened for maintenance purposes.
Design and installation versatility
The 90ESSE system offers various installation solutions including:
-
Extruded aluminum side guides (18 × 20 mm) with anti-noise gaskets
-
Option with stainless steel cable guide with spring system
-
Pre-painted aluminum terminal with telescopic caps
The upper structure integrates an inspectable galvanized steel channel containing the operating system, complete with 230V 50 Hz motor with pre-set limit switches and dedicated connectors.
