Structural supports for architectural constructions

Product lines for load-bearing architectural structures offer a wide range of solutions, from structural materials to beams and columns, designed to provide essential strength and stability. Quality and innovation come together to support the structure of buildings, facilitating the creation of robust and reliable architectural projects.

Structural supports for architectural constructions
Anchors for injection for Reinforcement of historical buildings - GBOS

Bossong

Anchors for injection for Reinforcement of historical buildings - GBOS
Over the last recent years a greater and greater attention to the existing building heritage and to the activities aimed to the preservation of both buildings with high architectural value and those belonging to the category of traditional buildings has been developed. Especially in reinforcement works, the Bossong company has carried out research on techniques and materials aimed at reinforcing masonry structures, proposing controlled injection anchors with sock for the consolidation of historic buildings, called GBOS. CHARACTERISTICS The system is composed by a strong element , a high strength stainless steel bar -AISI 304 or AISI 316- (ft nom 750 N/mm2 - fy nom 650 N/mm2 ), with full thread along the entire length. It is provided of a sock with the function of controlling the coaxially carried injection of the grout. These two elements, together with the grout, are fundamental to make integral the reinforcing element to the masonry. Besides allowing good injection operations, avoiding unexpected and often damaging spread of grout in voids and cavity that can be present in the existing walls, the sock guarantees the adherence of the injected material to the substrate throughout its entire length and a homogeneous distribution of stress thanks to both the adherence of injected material and the mechanical interlock that the injected grout develops with masonry. The line of anchors for controlled injection is complete with a range of accessories in AISI 316 stainless steel, couplers, turnbuckles, nuts, to fulfil the different needs of each project; Bossong can provide un-tensioned steel reinforcements, pre-stressed tendons, vertical anchors and anchors with every degree of tilt.

Mechanical anchors for seismic zone - NWS

Bossong

Mechanical anchors for seismic zone - NWS
In mechanical anchors section, the company Bossong proposes NWS type, suitable also for seismic areas, with cracked concrete and not. CHARACTERISTICS Bossong through anchor with external thread for middle-heavy duty loads. The application is rapid for through fastenings. The diameters are from 6 to 27 mm. The driving torque controlles expansion. The expansion clip is with anti-rotation fins. The most common type of fastener, ideal for the structural metalwork sector, plant engineering and door and window frames, and also ieal for concrete and natural stone resistant to compression. The stainless steel version for appearance and for installations in acid industrial environments and saline marine ones or in anywhere where the steel can suffer strong chemical attack.

Installation ruregold intrados slab

Laterlite

Systems of structural reinforcement | Ruregold
Ruregold of Laterlite is a leading company in the field of structural reinforcement and has a deep knowledge of the market of construction reconstruction and infrastructure maintenance, thanks to the significant know-how gained in almost 20 years of experience. Ruregold concentrates its energies in the evolution of new systems for the reinforcement of concrete and masonry structures with composites of excellence, in particular the FRCM range with PBO and carbon mesh and inorganic matrix that, first in the world, has obtained the international validation certification. Features The structural reinforcement systems FRCM (Fiber Reinforced Cementitious Matrix) consist of the coupling of a long fiber at high performance and inorganic matrix cementitious stabilized used with the function of adhesive: a step ahead of traditional FRP systems with composite matrix epoxy resins. Two different types of structural fibres, carbon and PBO (polyparafenilenbenzobisoxazole) are used in Ruregold’s FRCM reinforcement systems, both materialists with mechanical properties and performance that can absorb the efforts generated by overloads and exceptional events, such as earthquakes. The range also includes FRP reinforcement systems with carbon fibre pultruse fabrics and sheets and epoxy matrix consisting of the joining of a long high performance mechanical fibre and a matrix acting as an adhesive between the fibres and the support allowing the transfer of stresses from the structure to the fibre. The intervention of plating of the masonry, by means of the technique of the reinforced plaster - CRM system - allows the increase of the carrying and seismic capacityresistant to walls thanks to the use of fibreglass nets and specific mortars for the restoration and consolidation of masonry structures that allow to intervene especially in the case of walls are severely damaged or inconsistent, provided that the necessary transverse connections are in place and are well anchored to the reinforcements on both sides of the masonry. The range is completed with products and solutions for the restoration and preparation of the concrete and masonry support for subsequent structural reinforcement interventions, Fiber-reinforced HPFRC micro-extruders reinforced with steel and synthetic fibres for structural reinforcement of pillars, beams, beam-pillar knots and reinforcement hoods and X Plaster floor coverings.

Perimeter connector and screed

Laterlite

System of slab consolidation
Negli interventi di ristrutturazione degli edifici in muratura, I solai hanno un ruolo fondamentale per il consolidamento statico e antisismico degli edifici, grazie alla formazione della cerchiatura perimetrale che evita il ribaltamento delle pareti e alla formazione della soletta collaborante interconnessa al solaio esistente che crea un piano rigido. In particolare, l’obiettivo è quello di realizzare interventi tali da ottenere il “comportamento scatolare” del fabbricato esistente. L’efficace collegamento tra i solai e le pareti è indispensabile per assicurare la continuità strutturale degli elementi portanti dell’edificio: al solaio il compito di ridistribuire al meglio le forze orizzontali sulle pareti, formazione del piano rigido, oltre a evitarne il ribaltamento. Caratteristiche La realizzazione di una nuova soletta collaborante leggera, collegata al solaio esistente grazie al contributo dei Connettori CentroStorico Legno, Acciaio, Calcestruzzo, Chimico e alla muratura con Connettore CentroStorico Perimetrale, incrementa la sicurezza antisismica dell’edificio. Inoltre, la nuova soletta collaborante in Calcestruzzo Leca, collegata al solaio e alle pareti esistenti tramite i Connettori CentroStorico e Perimetrale, consente di ridurre il peso gravante sulle strutturesino al 50% rispetto a una soluzione tradizionale. Grazie anche al contributo dei massetti e sottofondi alleggeriti Leca, il sistema assicura positivi effetti sia sulla riduzione delle masse oscillanti durante l’evento sismico che sull’aumento della portata utile del solaio.

Sonne drums set in a living room

sonnen

Energy supply sonnenFlat 1500
The sonnenFlat is a system proposed by the Sonnen company, which aims at total energy independence, a cleaner and cheaper future, together with the sonnenBatterie. CHARACTERISTICS The idea behind the sonnenFlat is the combination with a photovoltaic system (guarantor of 75% of annual energy autonomy) with the sonnenBatterie system. The sonnenFlat, in fact, guarantees you the remaining 25% of energy needed as a reward for having made your sonnerBattery available to the national electricity grid. By joining the sonnenFlat 1500 you can enjoy monitoring by the service that helps to optimize self-production and self-consumption in your home, software updates available on the market to improve energy savings, energy bonuses of 1500 kWh annual to use when you need it. The sonnenFlat, in addition to creating the foundations for the electricity grid of the future, guarantees 100% independence and considerable economic advantages.

Plastbau Wall System 3

Poliespanso

Wall system | Plastbau 3
The Wall System Plastbau 3, is a custom formwork element for the casting of reinforced concrete supporting walls. It consists of two high-density EPS panels joined together and spaced out by metal lattices. The panels of standard width with design height, are placed side by side and form a rigid structure ready to receive the jet. Installation is carried out manually and is facilitated by special“U”profiles. The panels of the perimeter walls are prepared in the factory with the external slab suitably higher than the internal one at the height of the finished slab. Thanks to the three-dimensional iron lattice embedded in the panel, no additional formwork is required. A very simple hot blade instrument allows to dig quickly and cleanly the traces necessary for the installation of electrical and hydro-sanitary channels. CHARACTERISTICS The panel Plastbau®-3 has a vertical reinforcement duly integrated with horizontal reinforcement, allows to create structures in c.a. monolithic making the construction antiseismic. Its high versatility allows to adapt the system to the needs of the designer, with the appropriate calculations. These and other solutions allow to reduce the costs of realization, to improve the design and housing comfort of the buildings. You can also reach the value of insulation to air noise, through the use of the panels, which have a high sound-absorbing power. The thermal insulation power is also very high and varies depending on the thickness of the two walls of expanded polystyrene. Connected to the high thermal insulation power is the saving factor.

Plastbau sintered expanded polystyrene flooring

Poliespanso

Sintered expanded polystyrene slab | Plastbau Metal
The slabs in expanded polystyrene, or Plasbau Metal slabs, are composed of a self-supporting formwork panel in expanded polysitrene and galvanized metal profiles with variable geometry and built-in thermal insulation. This union between the foam mass and the metal inserts inside. With this type of systems it is possible to replace crumbling slabs without adding weight on structures and foundations, as well as a considerable ease of installation. It is also possible to optimize the thicknesses by positioning all the plant within the longitudinal slots in the panels. A fundamental characteristic of this extraordinary product is the insulation without thermal bridges. It also allows to minimize the thickness of the roof slabs. Its advantages are high housing comfort, energy saving, ease of transport and installation. CHARACTERISTICS In the series I - plaster the panels are coated at the bottom of a metal mesh in which the mortar is easily attached as the surface of the lower surface is already prepared. In the series C - ceiling panels are designed to remain raw and then be covered with panels using the sheets embedded in the panel. The series S - Sanitary, are not self-supporting panels, but are set up as sanitary floors on the ground floor, resting on a sand roof or as slabs superimposed on existing structures to be replaced.

Renovation of the Villafranca building with the FerriTECHNIC structural reinforcement and restoration system

Ferri

Structural restoration and consolidation system | FerriTECHNIC
Ferri has developed a structural restoration and consolidation system called FerriTECHNIC through the use of a range of new-concept materials and innovative techniques that are more effective and easier to apply, such as structural mortars and concrete suitable for the restoration and consolidation of deteriorated walls and facades, where different structural and construction elements often coexist, such as reinforced concrete, plaster and exposed bricks, to the detriment of the stability and aesthetic value of the facades themselves. Moreover, due to the deterioration to which the cementitious plasters are exposed, even safety can be compromised with the consequent risk of plaster detachment and danger of collapse. CHARACTERISTICS The damage that can occur in a building are of varying nature and extent, depending on the case, the system for facade Renovation works on moisture stains, which can prevent annoying and harmful leakage into the building and cracks. The system for Armed Structural Reinforcement uses a series of products, from nets to mortars, bio lime and connectors made of glass or carbon yarn, which are also highly performing in seismic areas. When the reinforced concrete degrades, leaving the reinforcement no longer sufficiently protected and subject to oxidation and increase in volume, a proper Restoration of the Concrete requires good protection of the reinforcement with certified products. The fresh Structural Concrete with modern formulations known as self-compacting ensures a homogeneous and uniform appearance, which is not required. In addition, the range of products includes Connectors suitable for structural interconnections of masonry even in seismic areas.

Architectural Load-Bearing Structures Pillars of the Building Project

Load-bearing structures are essential to support the weight of a building and ensure its stability. They must be designed considering the specific needs of the building, such as the type of load they will need to bear, the climatic conditions of the area, and the available materials. For example, in taller buildings, more complex structures may be required to handle vertical loads and lateral wind forces. Innovation in construction technologies has led to significant developments in load-bearing structures, with the use of advanced materials offering strength and flexibility, such as reinforced concrete, structural steel, and composite materials.
